6609031-5

Overview

The TE Connectivity Corcom Filters model 6609031-5 is a single-phase EMC/EMI line filter designed for chassis mounting. It operates at a rated voltage of 250VAC and supports a current capacity of 3A at 50/60Hz frequencies. The component features a two-stage filtering configuration with quick connect terminals, specifically .250" FASTON outputs and input connections. Certified by CSA, UR, and VDE standards, this filter is part of the R series and is suitable for general electronic applications requiring noise suppression.

Feature Summary

• Two-stage EMI/RFI filtering architecture for enhanced noise attenuation
• Quick connect terminal interface for simplified circuit integration
• Chassis mount design for secure mechanical installation
• Integrated safety certifications including UL, CSA, and VDE

Applications

• General electronic equipment noise suppression
• Industrial control systems power line filtering
• Medical device power input protection
• Information technology hardware EMI mitigation

Procurement Notes

Verify the specific terminal style compatibility before procurement, as the datasheet specifies .250" FASTON connections. Confirm that the chassis mounting requirements align with the physical dimensions provided in the official documentation. Ensure that the operating environment remains within the specified temperature range to maintain performance integrity and certification validity.

Selection Notes

Select this component when a single-phase, two-stage filter is required for 3A applications at 250VAC. The choice is driven by the need for quick-connect termination rather than wire leads. Consider the chassis mounting form factor if panel or internal rack space is limited. Verify that the EMI attenuation characteristics meet the specific electromagnetic compatibility requirements of the target system.

Part Context

This component belongs to the TE Connectivity Corcom Filters R series, which focuses on single-phase power line filters. The series provides solutions for general-purpose EMI/RFI suppression in various industrial and commercial sectors. The 6609031-5 variant specifically utilizes a chassis mount form factor with quick connect terminals, distinguishing it from panel mount or wire lead alternatives within the broader product family.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
