6609034-8

Overview

The TE Connectivity Corcom Filters 6609034-8 is a single-phase EMC/EMI line filter designed for power line applications. It features an IEC 320-C14 connector style with wire lead termination, enabling direct wiring integration. The component supports a rated current of 10 A and operates at 250 VAC within the 50/60 Hz frequency range. Constructed as a single-stage filter, it provides commercial-grade RFI suppression. The unit utilizes panel mount installation methods suitable for chassis or equipment enclosures.

Feature Summary

• Single-phase EMI/RFI filtering configuration
• IEC 320-C14 inlet interface with wire leads
• Commercial grade noise suppression
• Panel mount chassis integration

Applications

• Industrial control panels
• Medical equipment power supplies
• Commercial IT infrastructure
• Test and measurement instruments

Procurement Notes

Verify the specific datasheet version to confirm RoHS compliance status and exact physical dimensions prior to procurement. Ensure wire lead specifications match the target system's wiring harness requirements. Confirm that the panel cutout dimensions accommodate the mounting hardware. Cross-reference certification marks such as UL, CSA, and VDE against regional regulatory mandates for the intended deployment environment.

Selection Notes

Select this model when a 10 A capacity and single-stage filtration are required for AC power lines. The wire lead termination distinguishes it from snap-in variants, requiring appropriate crimping or soldering procedures. Evaluate the need for additional shielding if high-frequency interference is present in the operating environment. Consider thermal derating factors if ambient temperatures exceed standard operational limits.

Part Context

This component belongs to the TE Connectivity Corcom Filters series, specializing in electromagnetic interference mitigation for electronic systems. The product line offers various configurations including different current ratings and termination styles. This specific part represents a standard solution for general-purpose power entry modules requiring reliable noise reduction in commercial and industrial settings.

Replacement Considerations

Direct substitutes must match the 10 A rating, IEC 320-C14 interface, and wire lead termination. Verify equivalent single-stage filtering performance and identical panel mounting constraints. Ensure replacement parts maintain compatible voltage ratings and certification approvals for seamless integration without redesign.
