6609035-9

Overview

The TE Connectivity Corcom Filters 6609035-9 is a single-phase, two-stage EMI/RFI power line filter designed for chassis mounting. It features an IEC 320-C14 input connector with quick-connect terminals and supports a current rating of 10 A at 250 VAC. The unit provides an inductance of 7.13 mH and operates within a temperature range of -10°C to +40°C.

Feature Summary

• Two-stage filtering architecture for enhanced noise suppression
• Integrated IEC 320-C14 receptacle for standardized connection
• Chassis mount design with flanged installation

Applications

• Industrial equipment requiring EMI/RFI mitigation
• Medical devices needing stable power quality
• Test and measurement instrumentation

Procurement Notes

Verify the specific voltage and current requirements against the datasheet before ordering. Confirm that the chassis mounting dimensions and terminal types match your system design. Check for RoHS compliance status as indicated in official documentation.

Selection Notes

Select this model when a two-stage filter is required for 10 A applications. Ensure the operating environment stays within the specified temperature limits. Verify compatibility with the IEC 320-C14 standard for mating connectors.

Part Context

This component belongs to the Corcom SK series of single-phase filters. It is part of TE Connectivity's broader portfolio of power line conditioning solutions designed for commercial and industrial electronic systems.

Replacement Considerations

Consult official substitution guides for equivalent performance. No direct public substitute part numbers are confirmed in the provided data.
