6609045-2

Overview

The TE Connectivity Corcom Filters 6609045-2 is a single-phase EMC/EMI line filter designed for chassis mounting. It operates at a rated voltage of 250VAC and supports a current capacity of 6A at 50/60Hz. The component features a two-stage filtering configuration with quick-connect termination style, ensuring effective noise suppression in power line applications.

Feature Summary

• Single-phase EMC/EMI line filter design
• Two-stage filtering configuration
• Quick-connect termination style

Applications

• Power line noise suppression
• Chassis mounted equipment filtering
• General purpose EMI/RFI mitigation

Procurement Notes

Verify the active lifecycle status and confirm RoHS compliance before procurement. Ensure the quick-connect terminal type matches the system wiring requirements. Cross-reference the manufacturer datasheet for specific mechanical dimensions and mounting hardware details to guarantee proper integration into the target chassis assembly.

Selection Notes

Select this component for applications requiring single-phase filtering with a 6A rating. The two-stage design offers enhanced noise attenuation compared to single-stage alternatives. Verify that the chassis mounting style and quick-connect terminals are compatible with the existing system infrastructure and available installation space.

Part Context

This part belongs to the TE Connectivity Corcom Filters series, specializing in power line filters. The 6609045-2 model specifically addresses EMI/RFI interference in AC power lines. It is distinct from IEC receptacle modules by its dedicated filtering function and chassis mount form factor.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult the manufacturer's selector chart or technical support for equivalent components with matching electrical ratings and mounting configurations.
