6609046-5

Overview

The TE Connectivity Corcom Filters model 6609046-5 is a single-phase EMC/EMI line filter designed for chassis mounting. It supports a rated current of 6 A and operates at AC voltages up to 250 V within the 50/60 Hz frequency range. The unit features a single-stage configuration with wire lead termination style, providing essential noise suppression for power lines.

Feature Summary

• Provides single-stage electromagnetic interference (EMI) and radio frequency interference (RFI) filtering for single-phase power applications.
• Designed for secure chassis mounting to ensure stable installation in equipment enclosures.
• Utilizes wire lead terminations for direct electrical connection to circuit boards or internal wiring harnesses.

Applications

• Single-phase electronic equipment requiring EMI/RFI noise suppression
• Chassis-mounted industrial control systems
• Power supply input stages for general-purpose electronics

Procurement Notes

Verify that the specific application requires wire lead terminations rather than quick-connect terminals, as this distinguishes it from other SK series variants. Confirm chassis mounting compatibility and ensure the operating environment remains within the specified temperature limits. Cross-reference the manufacturer part number 6609046-5 against official TE Connectivity documentation to confirm current availability and standard lead times before finalizing procurement plans.

Selection Notes

Select this component when a single-stage filter is sufficient for the required attenuation levels. Ensure the system voltage does not exceed 250 VAC and the continuous current load remains at or below 6 A. Verify that the chassis mounting footprint and wire lead length meet the mechanical design constraints of the target enclosure.

Part Context

This component belongs to the TE Connectivity Corcom Filters lineup, which specializes in power line filters for various industrial and commercial applications. The 6609046-5 variant specifically addresses needs for single-phase filtering with wire leads, differing from models utilizing IEC connectors or different mounting styles within the same product family.

Replacement Considerations

Consult official TE Connectivity substitution guides for verified equivalents. Generic cross-references may not match the specific single-stage performance or wire lead termination requirements.
