Overview

The TE Connectivity Corcom Filters model 6609063-1 is a single-phase EMC/EMI line filter designed for board-level integration. It features PC pin termination and supports a rated current of 1 A at 250V AC, 50/60Hz. The component operates within a temperature range of -40°C to +85°C and complies with RoHS standards. This filter provides commercial-grade noise suppression for electronic equipment requiring compact power line filtering solutions.

Feature Summary

• Single-stage EMI/RFI noise suppression
• PC pin board mount termination
• Compact form factor for space-constrained designs

Applications

• Commercial electronic equipment power inputs
• Information technology hardware filtering
• Industrial control system power supplies

Procurement Notes

Verify the specific datasheet version and compliance certificates prior to ordering. Confirm that the PC pin pitch and mounting hole dimensions match the target PCB layout. Ensure the 1A current rating meets the application's peak load requirements without derating issues.

Selection Notes

Select this component when board-mount topology is required rather than panel or chassis installation. Compare against series P filters if higher current capacity or different termination styles are needed. Validate thermal performance under maximum load conditions to ensure stable operation within the specified temperature range.

Part Context

This part belongs to the TE Connectivity Corcom EBP series, which focuses on low-cost, high-volume board-level filtering. It complements the broader Corcom portfolio by offering a simplified solution for applications where integrated power entry modules are not feasible due to space constraints.

Replacement Considerations

Consult official substitution guides for equivalent ratings. Verify mechanical footprint compatibility before replacing with alternative manufacturers' components to avoid PCB redesign.
