6609075-9

Overview

The TE Connectivity Corcom Filters model 6609075-9 is a single-phase EMC/EMI power line filter designed for AC applications. It features a rated current of 15 A and operates at a voltage of 125 VAC. The component utilizes a single-stage filtering configuration and employs PC pin termination style for circuit board mounting.

Feature Summary

• Single-phase EMI/RFI filtering capability
• PC pin termination for PCB integration

Applications

• General electronic equipment power input stages

Procurement Notes

Verify the exact datasheet specifications against the manufacturer's official documentation before procurement. Confirm that the 125VAC rating and 15A current capacity align with the specific system requirements. Ensure the PC pin termination matches the target printed circuit board layout.

Selection Notes

Select this component when a single-stage, 15A single-phase EMI filter with PC pin termination is required. Verify compatibility with the intended operating voltage and current loads. Consider the physical dimensions and mounting constraints associated with the PC pin interface.

Part Context

This part belongs to the TE Connectivity Corcom Filters series, which specializes in electromagnetic interference suppression solutions. The product line includes various configurations for different current ratings and mounting styles, serving diverse industrial and commercial electronics markets.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
