6609974-4

Overview

The TE Connectivity Corcom Filters model 6609974-4 is a single-phase EMI/RFI line filter designed for chassis mounting. It features an IEC 320-C14 connector interface with quick-connect terminals rated at 0.187 inches (4.7mm). The component supports a maximum current of 6A and operates at voltages up to 250VAC within a frequency range of 50/60Hz. It includes dual fuse holders, though fuses are not included. The unit is certified by CSA, UR, and VDE agencies and functions reliably in ambient temperatures ranging from -10°C to 40°C.

Feature Summary

• Provides effective electromagnetic interference and radio frequency interference suppression for commercial and medical applications.
• Integrates dual fuse holders for enhanced circuit protection capabilities.
• Features a robust chassis mount design with standardized IEC 320-C14 input interface.

Applications

• Regenerative motor drive systems
• Commercial electronic equipment requiring EMI filtering
• Medical devices needing RFI suppression

Procurement Notes

Verify the specific datasheet version and certification marks (CSA, UR, VDE) against your regional regulatory requirements before finalizing procurement. Confirm that the required fuses are sourced separately as they are not included with the module. Ensure the chassis opening dimensions accommodate the rectangular panel cutout specifications provided in the official documentation.

Selection Notes

Select this component when a 6A rating and 250VAC capability are required for single-phase power lines. The chassis mount style and IEC 320-C14 interface make it suitable for enclosed industrial or medical enclosures. Consider the operating temperature range of -10°C to 40°C to ensure compatibility with the intended environment.

Part Context

This part belongs to the TE Connectivity Corcom Filters product line, specializing in power line filters. It is categorized under EMI/RFI filters for commercial and medical use. The manufacturer identifies it as a single-stage filter module designed for reliable noise reduction in sensitive electronic applications.

Replacement Considerations

Publicly confirmed substitute part numbers were not found in the provided source material. Consult official distributor databases for cross-reference data if alternative sourcing is necessary.
