67997-600H

Headers, Male Pins Overview

The Amphenol ICC (FCI) 67997-600H is a BergStik® II series pin header connector designed for board-to-board applications. It features a 2-row configuration with 45 positions and a 2.54 mm pitch. The connector utilizes through-hole termination with solder pins and straight mounting style. Contact materials are phosphor bronze, and the housing is black thermoplastic rated UL 94 V-0. It supports a maximum current rating of 5 A per contact and operates within a temperature range of -65°C to +130°C.

Headers, Male Pins Feature Summary

• BergStik® II modular mezzanine system design
• Unshrouded vertical pin-in-socket architecture
• Through-hole solder termination for secure PCB attachment

Headers, Male Pins Applications

• Board-to-board interconnections
• High-density electronic assemblies
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify RoHS compliance status as the 'H' suffix may indicate non-RoHS specifications compared to 'HLF' variants. Confirm lead-free availability if required by project standards. Cross-reference datasheet revisions for material changes. Ensure mating connectors match the 2.54mm pitch and unshrouded header requirements. Validate thermal ratings against operational environment constraints.

Headers, Male Pins Selection Notes

Select this component for high-current applications requiring robust mechanical stability in vertical orientations. The 5A rating per contact distinguishes it from lower-rated alternatives. Consider the unshrouded design for space-constrained layouts where shrouds are unnecessary. Verify compatibility with existing PCB footprint designs and mating socket components.

Headers, Male Pins Part Context

Part of the BergStik® II family, offering modular scalability. Designed for reliable performance in demanding environments. Complements other FCI interconnect solutions for complete system integration.

Headers, Male Pins Replacement Considerations

67997-600HLF offers identical electrical and mechanical specifications with guaranteed lead-free compliance. Verify housing color and terminal plating differences when substituting.
