68016-113HLF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 68016-113HLF is a board-to-board connector header from the BergStik II series. It features a single row with 13 positions and a 2.54mm pitch. The component utilizes right-angle through-hole mounting for solder termination. Contacts are made of phosphor bronze with tin over nickel plating. The housing is black thermoplastic rated UL94 V-0.

Headers, Male Pins Feature Summary

• Right-angle through-hole design for PCB integration
• Single-row configuration with 13 male contacts
• Tin over nickel contact plating for corrosion resistance

Headers, Male Pins Applications

• Board-to-board interconnection systems
• Industrial control equipment
• Telecommunications infrastructure

Headers, Male Pins Procurement Notes

Verify RoHS compliance status as original datasheets may indicate lead-free construction while older revisions might differ. Confirm that the specific ordering suffix matches the required pin count and orientation. Ensure compatibility with mating socket connectors in the same series to maintain proper alignment and electrical continuity during assembly.

Headers, Male Pins Selection Notes

Select this part for applications requiring right-angle signal routing on dense PCB layouts. The 2.54mm pitch ensures broad compatibility with standard components. Verify thermal requirements against the operating temperature range. Consider mechanical stability provided by the through-hole solder joints for vibration-prone environments.

Headers, Male Pins Part Context

This component belongs to the BergStik II family, a modular mezzanine system designed for reliable board-to-board connections. The series offers various configurations including straight and right-angle headers. It supports high-density applications in data processing and communication devices requiring robust signal integrity.

Headers, Male Pins Replacement Considerations

• 68016-113LF
