Product Detailed Parameters
- Description：LINE FILTER 32A CHASSIS MOUNT
- Series：6SL3202
- Mfr：Siemens
- Package：Box
- Filter Type：-
- Configuration：-
- Voltage - Rated DC：-
- Voltage - Rated AC：-
- Current：32 A
- Frequency - Operating：-
- Applications：-
- Approval Agency：-
- Operating Temperature：-
- Mounting Type：Chassis Mount
- Termination Style：Terminal Block
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The Siemens 6SL3202-0AJ23-2CA0 is a SINAMICS output reactor designed for motor drive applications. It functions as a load-side output choke compatible with Power Modules featuring FSC base mounting capabilities. The unit operates within a three-phase (3AC) supply voltage range of 380Vac to 480Vac, covering standard ratings such as 400Vac, 415Vac, and 440Vac. Electrical connections are established via screw terminals, ensuring secure integration into industrial control systems.
Feature Summary
- Functions as a load-side output reactor for SINAMICS drives
- Supports FSC base mounting on compatible Power Modules
- Utilizes screw connection technology for electrical interfacing
Applications
- SINAMICS motor drive systems
- Industrial motion control setups
- Power module output filtering
Procurement Notes
Verify the specific article number 6SL3202-0AJ23-2CA0 against your system requirements. Confirm compatibility with your existing SINAMICS Power Module and FSC base configuration. Ensure the input voltage matches the 380Vac-480Vac specification. Request official datasheets to validate technical parameters before finalizing procurement decisions.
Selection Notes
Select this component when integrating SINAMACS drives requiring load-side output chokes. It is suitable for three-phase systems operating between 380Vac and 480Vac. The design supports FSC base mounting, making it appropriate for specific Power Module architectures. Verify terminal connection types match your installation needs.
Part Context
This component belongs to the Siemens SINAMICS family of motor drive accessories. It serves as an output reactor specifically engineered for use with Power Modules. The product line focuses on enhancing drive performance through improved signal integrity and harmonic reduction in industrial automation environments.
Replacement Considerations
Consult Siemens documentation for verified substitute part numbers. Cross-reference specifications to ensure identical voltage ranges and mounting compatibility. Generic equivalents may not support the specific FSC base mounting requirement.
