6SL32030BE325AA0

$1,866.62

Description：LINE FILTER 250A CHASSIS MOUNT
Series：-
Mfr：Siemens
Package：Box

SKU:b93a3bedc025 Category: Power Line Filter Modules Brand: Siemens

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LINE FILTER 250A CHASSIS MOUNT
Series：-
Mfr：Siemens
Package：Box
Filter Type：-
Configuration：-
Voltage - Rated DC：-
Voltage - Rated AC：-
Current：250 A
Frequency - Operating：-
Applications：-
Approval Agency：-
Operating Temperature：-
Mounting Type：Chassis Mount
Termination Style：Threaded Post (M8)
Inductance：-
Voltage - Rated AC (Phase to Ground/Neutral)：380 V
Voltage - Rated AC (Phase to Phase)：480 V

Download product information

6SL32030BE325AA0

Overview

The Siemens 6SL32030BE325AA0 is a SINAMICS additional line filter module designed for Class A electromagnetic compatibility. It is engineered for use with Power Module PM240 FSF units rated from 110 kW. The device operates on a low voltage three-phase AC input of 380 to 480 V and supports a current rating of 250 A. Its physical dimensions are 360 mm in height, 240 mm in width, and 116 mm in depth.

Feature Summary

Provides Class A EMC filtering for industrial drive systems
Compatible with SINAMICS PM240 FSF power modules
Designed for high-power applications starting at 110 kW

Applications

SINAMICS G120 drive systems
Industrial motor drives requiring EMC compliance
Power module PM240 FSF integration

Procurement Notes

Verify the specific application requirements against the official Siemens technical data sheet before procurement. Confirm that the installation environment supports the specified voltage range of 380-480V AC and the current capacity of 250A. Ensure compatibility with the target Power Module PM240 FSF unit. Check for any regional distribution restrictions or availability constraints directly with authorized Siemens channels or distributors prior to ordering.

Selection Notes

Select this component when Class A emission limits are required for SINAMICS drives powered by PM240 FSF modules. It is suitable for three-phase systems operating between 380V and 480V. Ensure the load current does not exceed 250A. This filter is specifically intended for power ratings of 110 kW and above within the compatible module series.

Part Context

This line filter belongs to the Siemens SINAMICS accessory family, specifically designed to enhance electromagnetic compatibility for drive systems. It serves as an add-on component for the PM240 FSF power modules, ensuring adherence to industrial EMC standards. The module integrates into the drive architecture to mitigate conducted emissions generated by the power electronics.
