6U-30.720MBE-T

Oscillators Overview

The 6U-30.720MBE-T is a Voltage-Controlled Crystal Oscillator (VCXO) manufactured by TXC Corporation, operating at a nominal frequency of 30.72 MHz. It utilizes CMOS output format and functions within a supply voltage range of 3.3 V. The component supports amplitude control features and is housed in a compact 6-SMD, No Lead package with dimensions of 5.00 mm x 3.20 mm. Designed for industrial environments, it maintains operational stability across a temperature range of -40°C to +85°C.

Oscillators Feature Summary

• Voltage-controlled crystal oscillator architecture enabling precise frequency tuning via external control signals.
• CMOS output interface providing digital signal compatibility for low-voltage logic circuits.
• Integrated amplitude control functionality to maintain consistent signal integrity under varying conditions.

Oscillators Applications

• Clock generation systems requiring adjustable frequency parameters.
• Telecommunications equipment utilizing standard baseband frequencies.
• Industrial control modules demanding stable timing references in variable thermal environments.

Oscillators Procurement Notes

Verify the specific manufacturing lot date code and RoHS compliance status directly with authorized distributors or the manufacturer prior to procurement. Confirm that the 6-SMD no-lead package orientation matches your PCB footprint design requirements. Ensure that the 3.3V supply voltage aligns with your system's power distribution network to prevent overvoltage damage. Check for any recent product change notices regarding pinout or electrical characteristics updates.

Oscillators Selection Notes

Select this component when a fixed-frequency oscillator is insufficient for your application's need for frequency modulation or compensation. The VCXO type allows for dynamic adjustment, making it suitable for phase-locked loop applications. Ensure your circuit design accommodates the control voltage input required for amplitude and frequency regulation. Verify that the CMOS output swing meets the input threshold requirements of downstream logic components.

Oscillators Part Context

This part belongs to the 6U series of VCXOs from TXC Corporation, designed for surface-mount assembly. The series typically offers high stability and low phase noise characteristics suitable for precision timing applications. The 30.72 MHz frequency is commonly used in telecommunications and data transmission standards. The no-lead package design facilitates automated placement and improves thermal performance compared to traditional leaded packages.

Oscillators Replacement Considerations
