Description：LINE FILTER 250VAC 16A CHASS MNT
Series：WG
Mfr：TE Connectivity Corcom Filters
Package：Bulk

SKU:5440b0b789e1 Category: Power Line Filter Modules Brand: TE Connectivity Corcom Filters

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LINE FILTER 250VAC 16A CHASS MNT
Series：WG
Mfr：TE Connectivity Corcom Filters
Package：Bulk
Filter Type：Single Phase
Configuration：Single Stage
Voltage - Rated DC：-
Voltage - Rated AC：250V
Current：16 A
Frequency - Operating：50/60Hz
Applications：General Purpose
Approval Agency：CSA, UR, VDE
Operating Temperature：-10°C ~ 40°C
Mounting Type：Chassis Mount
Termination Style：Threaded Post (M8), Wire Leads
Inductance：2.1mH

Download product information

7-6609089-8

Overview

The TE Connectivity Corcom Filters model 7-6609089-8 is a single-phase EMI/RFI power line filter module designed for chassis mounting. It features a rated AC voltage of 250V and a continuous current capacity of 16A at operating frequencies of 50Hz and 60Hz. The component utilizes faston terminal connections for circuit integration. Certified by CSA, UL, and VDE agencies, it supports general industrial applications requiring electromagnetic interference suppression.

Feature Summary

Provides single-phase EMI/RFI noise attenuation for power lines
Engineered for secure chassis mounting installation
Utilizes faston terminals for direct circuit board connection

Applications

Industrial machinery power input stages
Medical equipment power supplies
General electronic device EMC compliance

Procurement Notes

Verify the specific manufacturer part number against official TE Connectivity documentation to ensure authenticity. Confirm that the faston terminal dimensions match your PCB requirements. Check for RoHS compliance status in the latest datasheet as manufacturing standards may evolve. Ensure the chassis mounting hole pattern aligns with your enclosure design specifications before procurement.

Selection Notes

Select this component when a 16A single-phase filter is required for chassis-mounted applications. Ensure the 250VAC rating meets your system's voltage requirements. Verify that the faston terminal style is compatible with your wiring harness or PCB layout. Consider the physical dimensions for adequate clearance within the equipment enclosure during the design phase.

Part Context

This component belongs to the TE Connectivity Corcom Filters series, which specializes in electromagnetic interference suppression solutions. The product line offers various configurations for different current ratings and mounting styles. This specific model addresses high-current single-phase filtering needs in compact chassis-mounted form factors for industrial and commercial electronics.
