70095-16A8

Headers, Male Pins Overview

The BellWether 70095-16A8 is a male pin header connector designed for through-hole mounting with a right-angle orientation. It features a 16-position configuration arranged in a single row. The connector utilizes a 3.00mm (0.118 inch) pitch spacing between pins, providing standardized alignment for PCB integration. This component serves as a reliable interface solution for signal transmission within electronic assemblies requiring secure mechanical attachment and consistent electrical contact.

Headers, Male Pins Feature Summary

• Right-angle design facilitates compact board stacking and space-constrained layouts
• Through-hole termination method ensures robust mechanical stability on printed circuit boards
• Single-row 16-pin configuration supports dense interconnection requirements

Headers, Male Pins Applications

• Industrial control system interfaces
• Embedded device signal routing
• Communication infrastructure hardware connections

Headers, Male Pins Procurement Notes

Verify the specific datasheet version to confirm material specifications and plating details before finalizing procurement decisions. Ensure that the right-angle footprint matches the target PCB layout dimensions precisely. Cross-reference the 3.00mm pitch requirement with mating connectors to guarantee compatibility. Confirm that the through-hole drilling specifications align with standard manufacturing capabilities to avoid assembly issues during production.

Headers, Male Pins Selection Notes

Select this component when a rigid, right-angle connection is required for 16 signals with a 3.00mm spacing. Evaluate the mechanical stress environment to ensure through-hole mounting provides sufficient durability. Consider the available vertical clearance on the PCB to accommodate the right-angle profile without interference from adjacent components or chassis structures.

Headers, Male Pins Part Context

This part belongs to BellWether's Micro-Hi series of right-angle headers. The series focuses on providing reliable interconnect solutions for demanding applications. BellWether specializes in designing connectors, cables, and flexible printed circuit assemblies for industries requiring high reliability. This specific model represents a standard pin header option within their broader portfolio of electronic interconnection products.

Headers, Male Pins Replacement Considerations

Consult official BellWether documentation for direct cross-references. Verify that any substitute maintains the identical 3.00mm pitch and 16-position count. Ensure the replacement also offers right-angle orientation and through-hole termination to preserve mechanical fit and electrical characteristics.
