70096-08C8

Headers, Male Pins Overview

The BellWether 70096-08C8 is a male pin header connector designed for through-hole mounting. It features an eight-position configuration with a right-angle orientation, facilitating efficient PCB layout in space-constrained applications. The component belongs to the Micro-Hi series, which utilizes a 3.00mm pitch to ensure reliable electrical connectivity. This specific model supports surface mount and through-hole options within the broader family, offering robust performance for various electronic equipment interfaces.

Headers, Male Pins Feature Summary

• Right-angle male pin header configuration for vertical PCB insertion
• Eight-position contact array ensuring stable signal transmission
• Through-hole mounting technology for secure mechanical attachment
• Compatible with standard edgeboard connection requirements

Headers, Male Pins Applications

• General-purpose electronic equipment interconnects
• Edgeboard connections requiring right-angle routing
• Consumer electronics internal circuit board linking
• Industrial control system interface modules

Headers, Male Pins Procurement Notes

Verify the exact part number against official BellWether documentation to confirm the right-angle through-hole specification. Ensure compatibility with the target PCB hole size and pitch requirements. Cross-reference the Micro-Hi series datasheet for current ratings and material specifications before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a right-angle through-hole header is required for eight-pin connections. Consider the 3.00mm pitch constraint of the Micro-Hi series. Evaluate spatial limitations on the PCB to accommodate the right-angle profile. Confirm that the through-hole mounting method aligns with the assembly process capabilities.

Headers, Male Pins Part Context

This connector is part of the BellWether Micro-Hi series, a comprehensive system designed for high-density interconnects. The series offers multiple mounting options including surface mount and through-hole variants. The 70096-08C8 specifically addresses the need for right-angle connectivity within this ecosystem, providing a standardized solution for edgeboard applications.

Headers, Male Pins Replacement Considerations

Consult BellWether's official substitution list for compatible alternatives. Verify that any replacement maintains the 8-position count, right-angle orientation, and through-hole mounting style. Ensure the pitch and current rating match the original design requirements to prevent functional discrepancies.
