70316-E4J8

Headers, Male Pins Overview

The BellWether 70316-E4J8 is a male pin header connector designed for through-hole mounting with a right-angle configuration. It features a total of 16 positions, specifically configured as 12 power pins and 4 signal pins. The component utilizes a 3.0mm pitch standard to support high-density applications while maintaining electrical performance. It is rated for single-pin currents up to 12.5A, making it suitable for server and high-power equipment power supplies. The insulation height measures 0.390 inches (9.91mm), and the housing is black.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting design for space-efficient PCB integration
• High current capacity supporting up to 12.5A per pin for stable power transmission
• Mixed pin configuration combining 12 power and 4 signal positions in a single unit
• Anti-misinsertion design to ensure correct orientation during assembly

Headers, Male Pins Applications

• Data center server power systems
• Industrial automation equipment
• Energy storage cabinets
• Medical devices requiring high reliability

Headers, Male Pins Procurement Notes

Verify that the specific part number 70316-E4J8 matches the required 16-position mixed configuration of 12 power and 4 signal pins. Confirm the right-angle through-hole mounting style aligns with the target PCB layout. Ensure the 3.0mm pitch specification meets the board design requirements. Check for RoHS compliance and halogen-free material certification if environmental standards are mandated by the project specifications.

Headers, Male Pins Selection Notes

Select this component when high current density is required within a limited spatial footprint on a printed circuit board. The 3.0mm pitch offers a balance between connection density and electrical isolation. Consider the right-angle form factor for vertical interconnect needs or cable management constraints. Validate that the 12.5A current rating per pin satisfies the maximum load requirements of the power distribution network without excessive thermal rise.

Headers, Male Pins Part Context

This connector belongs to the BellWether Micro-Hi™ series, which is engineered for high-density and high-current applications. The series is widely utilized in demanding environments such as server infrastructure and industrial power systems where reliable electrical connections under high load are critical. The product line emphasizes robust construction and precise manufacturing to ensure consistent performance across various electronic assemblies.

Headers, Male Pins Replacement Considerations

No public confirmed substitute part numbers are available for this specific model. When replacing, verify exact dimensional compatibility, including the 3.0mm pitch and 0.390-inch insulation height. Ensure the replacement maintains the same 16-position mixed configuration and current carrying capabilities to preserve system integrity.
