Headers, Male Pins Overview

Molex part number 70543-0018 is a wire-to-board connector header designed for signal applications. It features a vertical orientation with a 2.54 mm pitch and contains 19 positions. The component is rated for a maximum current of 3 A and a voltage of 250 V. It operates within a temperature range of -40 °C to +105 °C. The housing is packaged in tubes.

Headers, Male Pins Feature Summary

• Vertical mounting configuration for PCB integration
• Male pin interface for wire-to-board connection
• Signal application design with specified electrical ratings

Headers, Male Pins Applications

• General electronic circuit interconnections
• Industrial control panel wiring
• Consumer electronics assembly

Headers, Male Pins Procurement Notes

Verify the exact part number format, as the input model lacks hyphens. Confirm that the 19-position variant matches the specific system requirement. Check RoHS compliance status through official manufacturer documentation before finalizing procurement decisions.

Headers, Male Pins Selection Notes

Select this component when a 19-position vertical header is required. Ensure the mating wire gauge and terminal type align with the 3 A current rating. Verify that the 2.54 mm pitch fits the available board layout space.

Headers, Male Pins Part Context

This header belongs to Molex's standard wire-to-board connector family. It provides a reliable mechanical and electrical connection between flexible wires and rigid printed circuit boards. The design supports automated assembly processes common in modern manufacturing environments.

Headers, Male Pins Replacement Considerations

Consult official Molex cross-reference guides for verified substitutes. Generic equivalents may differ in material properties or locking mechanisms. Validate dimensional compatibility before replacing the original component.
