Product Detailed Parameters
- Description：RF ANT 2.4425GHZ BLAD RP-SMA ADH
- Series：MiniBlade
- Mfr：Amphenol PCTEL
- Package：Box
- RF Family/Standard：Cellular, WiFi
- Frequency Group：Wide Band
- Frequency (Center/Band)：2.4425GHz, 3.6GHz, 5.425GHz, 6.525GHz
- Frequency Range：2.4GHz ~ 2.485GHz, 3.4GHz ~ 3.8GHz, 4.9GHz ~ 5.95GHz, 5.925GHz ~ 7.125GHz
- Antenna Type：Blade
- Number of Bands：4
- VSWR：2, 3
- Return Loss：-
- Gain：3.8dBi, 5dBi, 7dBi, 5dBi
- Features：Cable - 500mm
- Termination：RP-SMA
- Ingress Protection：-
- Grade：-
- Qualification：-
- Mounting Type：Adhesive
- Height (Max)：0.260" (6.60mm)
- Applications：5G, CBRS, Wi-Fi 6E
- Power - Max：-
Download product information
Overview
The Amphenol PCTEL 710631 is a Smarteq MiniBlade antenna designed for indoor applications supporting 5G, CBRS, and Wi-Fi 6E bands. It features an RP-SMA connector and utilizes adhesive mounting for curved surfaces. The unit operates within a frequency range of 2.4 GHz to 7.125 GHz and supports Bluetooth protocols. The design ensures IP65 protection and superior RF performance in compact environments.
Feature Summary
- Slim and flexible blade construction suitable for curved surface mounting
- IP65 rated enclosure for environmental protection
- Integrated RP-SMA connector interface
- Adhesive-based installation method
Applications
- 5G network infrastructure deployment
- CBRS band signal distribution
- Wi-Fi 6E indoor coverage enhancement
- Bluetooth connectivity integration
Procurement Notes
Verify the specific datasheet version to confirm exact electrical parameters and mechanical dimensions. Ensure the RP-SMA connector type matches system requirements. Confirm adhesive mounting compatibility with target surfaces. Check IP65 rating validity for intended environmental conditions. Validate frequency range specifications against application needs.
Selection Notes
Select this model for indoor installations requiring discreet antenna solutions. Consider the flexible blade design for non-planar mounting surfaces. Verify compatibility with RP-SMA mating connectors. Assess environmental exposure to ensure IP65 adequacy. Evaluate frequency coverage against specific 5G, CBRS, or Wi-Fi 6E requirements.
Part Context
This component belongs to the Amphenol PCTEL Smarteq MiniBlade series. It is categorized as an indoor antenna solution. The product line focuses on wireless technology integration for modern communication standards. The manufacturer provides specialized antenna systems for diverse deployment scenarios.
