734090030

Overview

Molex part number 73409-0030 is a female SMC coaxial connector with a bulkhead mounting style. It features a clamp termination method designed for RG-178 and RG-196 cable types. The component operates at an impedance of 50 Ohms and utilizes brass body material with gold plating on both the body and contacts.

Feature Summary

• Provides secure bulkhead mounting for panel integration
• Utilizes a clamp termination mechanism for reliable cable attachment
• Features gold-plated contacts to ensure signal integrity

Applications

• RF interconnect applications requiring 50 Ohm impedance
• Panel-mounted coaxial connections using RG-178 or RG-196 cables

Procurement Notes

Verify the exact suffix against official Molex documentation, as variations may exist within the 73409 series. Confirm that the specific order matches the bulkhead orientation and clamp termination style required for your assembly. Cross-reference the cable compatibility list to ensure RG-178 or RG-196 specifications are met before procurement.

Selection Notes

Select this component when a female SMC connector with a bulkhead configuration is required. Ensure the design accommodates the clamp termination style rather than crimp or solder variants. Verify that the operating environment supports the standard temperature range and that the 50 Ohm impedance aligns with the system requirements.

Part Context

This component belongs to the Molex SMC series of RF connectors. The SMC type is a subminiature version of the SMB connector, offering similar performance in a smaller form factor. This specific variant is distinguished by its bulkhead mounting capability and suitability for semi-rigid or flexible coaxial cables like RG-178 and RG-196.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source data.
