Product Detailed Parameters
- Description：FERRITE BEAD 580 OHM 3318 1LN
- Series：WE-SUKW
- Mfr：Würth Elektronik
- Package：Tape & Reel (TR),Cut Tape (CT)
- Filter Type：-
- Number of Lines：1
- Impedance @ Frequency：580 Ohms @ 100 MHz
- Current Rating (Max)：5A
- DC Resistance (DCR) (Max)：12mOhm
- Ratings：-
- Operating Temperature：-40°C ~ 125°C
- Package / Case：3318 (8546 Metric)
- Mounting Type：Surface Mount
- Height (Max)：0.217" (5.50mm)
- Size / Dimension：0.335" L x 0.183" W (8.50mm x 4.65mm)
- Features：-
Download product information
Overview
The Wurth Elektronik 7427512 is a Surface Mount Device (SMD) EMI suppression ferrite bead belonging to the WE-SUKW series. It features a five-hole design with an impedance of 580 Ohms at 25 MHz and a DC current rating of 5 Amperes. The component measures 8.50 mm in length and 4.65 mm in width, with a maximum height of 5.50 mm. It utilizes a special NiSn pad configuration to enhance soldering results and complies with AEC-Q200 automotive standards.
Feature Summary
- Five-hole structural design for enhanced electromagnetic interference suppression
- Special NiSn pad configuration to improve soldering reliability
- Automotive grade qualification compliant with AEC-Q200 standards
Applications
- Automotive electronic circuit protection
- High-current signal line filtering
- EMI suppression in compact surface mount assemblies
Procurement Notes
Verify the specific datasheet version to confirm exact impedance tolerances and thermal characteristics. Ensure the ordering part number matches the required package dimensions and pin configuration. Confirm compliance requirements such as RoHS and REACH status before finalizing procurement specifications.
Selection Notes
Select this component when high current handling up to 5A is required alongside significant impedance at 25 MHz. The five-hole architecture allows for greater magnetic path efficiency compared to single-hole beads. Verify that the PCB footprint accommodates the 8.50 mm x 4.65 mm dimensions and 5.50 mm height constraint.
Part Context
This component is part of the WE-SUKW series from Wurth Elektronik, designed specifically for SMD applications requiring robust EMI filtering. The series emphasizes high current capacity and reliable soldering through specialized pad designs, catering to industries demanding strict quality and performance standards.
Replacement Considerations
Cross-reference with other Wurth Elektronik WE-SUKW variants or comparable five-hole SMD ferrites from other manufacturers. Ensure replacement parts match the 580 Ohm impedance at 25 MHz and 5A current rating. Verify physical footprint compatibility and AEC-Q200 certification if used in automotive contexts.
