744253101

$1.97

Description：CMC 100UH 450MA 3LN SMD
Series：WE-SL3
Mfr：Würth Elektronik
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:12f55ecdcfd3 Category: Common Mode Chokes Brand: Würth Elektronik

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 100UH 450MA 3LN SMD
Series：WE-SL3
Mfr：Würth Elektronik
Package：Tape & Reel (TR),Cut Tape (CT)
Filter Type：Signal Line
Number of Lines：3
Current Rating (Max)：450mA
DC Resistance (DCR) (Max)：-
Voltage Rating - DC：80V
Voltage Rating - AC：-
Operating Temperature：-40°C ~ 125°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Surface Mount
Size / Dimension：-
Height (Max)：0.098" (2.50mm)
Package / Case：-
Inductance @ Frequency：100 µH @ 100 kHz
Impedance @ Frequency：-
Qualification：-
Grade：-

Download product information

744253101

Overview

The Würth Elektronik 744253101 is a surface-mount common mode line filter from the WE-SL3 series. It features an inductance of 100 µH and an impedance of 5 kΩ at 1 kHz. The component supports a maximum DC current of 450 mA with a maximum DC resistance of 0.45 Ω. Designed for operation between -40 °C and +125 °C, it utilizes a compact SMD package measuring 9.2 mm x 6.6 mm x 2.5 mm. The device complies with RoHS and REACH standards.

Feature Summary

Provides effective common mode noise suppression for signal lines
Utilizes a compact surface-mount design for automated assembly
Operates reliably across a wide industrial temperature range

Applications

General electronic equipment signal filtering
Industrial control system interface protection
Consumer electronics data line noise reduction

Procurement Notes

Verify the specific part number against official Wurth Elektronik documentation to ensure accuracy. Confirm that the required electrical parameters, including inductance and current ratings, align with the target circuit design. Check for compliance certifications such as RoHS and REACH if mandated by the end product regulations. Ensure the surface-mount footprint dimensions match the PCB layout constraints.

Selection Notes

Select this component when a low-profile common mode choke is required for space-constrained designs. The 100 µH inductance offers balanced filtering performance for moderate noise environments. Consider the 450 mA current rating to ensure the component does not saturate under normal operating conditions. The wide temperature range makes it suitable for applications subject to thermal variation.

Part Context

This component belongs to the WE-SL3 series of surface-mount common mode filters. The series is characterized by its small form factor and high reliability for general electronic applications. It serves as a passive electromagnetic interference suppression solution for single-channel lines.
