Description：FIXED IND 390UH 680MA 690MOHM SM
Series：WE-PD
Mfr：Würth Elektronik
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:40cf560944d1 Category: Fixed Inductors Brand: Würth Elektronik

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

744771239 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Würth Elektronik. Its product description is FIXED IND 390UH 680MA 690MOHM SM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for 744771239

Description：FIXED IND 390UH 680MA 690MOHM SM
Series：WE-PD
Mfr：Würth Elektronik
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Drum Core, Wirewound
Material - Core：Manganese Zinc Ferrite (MnZn)
Inductance：390 µH
Tolerance：±20%
Current Rating (Amps)：680 mA
Current - Saturation (Isat)：850mA
Shielding：Shielded
DC Resistance (DCR)：690mOhm Max
Q @ Freq：-
Frequency - Self Resonant：2.8MHz
Ratings：AEC-Q200
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：1 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.472" L x 0.472" W (12.00mm x 12.00mm)
Height - Seated (Max)：0.236" (6.00mm)
Features：-

Fixed Inductors datasheet and documents for 744771239

744771239

Fixed Inductors Overview

The Würth Elektronik 744771239 is a shielded surface-mount power inductor from the WE-PD series. It features a ferrite drum core and wirewound construction with an inductance of 390 µH and a tolerance of ±20%. The component supports a maximum DC current of 680 mA and has a maximum DC resistance of 690 mOhms. Saturation current is rated at 680 mA, with a self-resonant frequency of 1.5 MHz measured at 100 kHz. It operates within a temperature range of -40°C to +125°C and holds AEC-Q200 qualification.
