7447783102

$1.92

Description：FIXED IND 1MH 230MA 4.6 OHM SMD
Series：WE-PD Performance
Mfr：Würth Elektronik
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:42078dc81e58 Category: Fixed Inductors Brand: Würth Elektronik

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

7447783102 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Würth Elektronik. Its product description is FIXED IND 1MH 230MA 4.6 OHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for 7447783102

Description：FIXED IND 1MH 230MA 4.6 OHM SMD
Series：WE-PD Performance
Mfr：Würth Elektronik
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Drum Core, Wirewound
Material - Core：Ferrite
Inductance：1 mH
Tolerance：±20%
Current Rating (Amps)：230 mA
Current - Saturation (Isat)：320mA
Shielding：Shielded
DC Resistance (DCR)：4.6Ohm Max
Q @ Freq：-
Frequency - Self Resonant：2.2MHz
Ratings：AEC-Q200
Operating Temperature：-40°C ~ 150°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.291" L x 0.287" W (7.40mm x 7.30mm)
Height - Seated (Max)：0.138" (3.50mm)
Features：-

Fixed Inductors datasheet and documents for 7447783102

7447783102

Fixed Inductors Overview

The Würth Elektronik 7447783102 is a shielded surface-mount power inductor from the WE-PD series. It features a drum core wirewound construction with a ferrite magnetic material. The component provides an inductance of 1 mH with a tolerance of ±20%. It supports a maximum DC current of 230 mA and has a maximum DC resistance of 4.6 Ohms. The device measures 7.3 mm in length, 7.4 mm in width, and complies with AEC-Q200 automotive standards.

Fixed Inductors Feature Summary

Shielded drum core design minimizes electromagnetic interference
AEC-Q200 qualified for automotive reliability requirements
Surface mount package facilitates automated assembly

Fixed Inductors Applications

Automotive electronics power circuits
General-purpose DC-DC converter filtering
Industrial control system power supplies

Fixed Inductors Procurement Notes

Verify the manufacturer part number 7447783102 against official Wurth Elektronik documentation to ensure authenticity. Confirm that the received components match the specified 1 mH inductance and 230 mA current ratings. Check for physical damage to the surface mount terminals. Ensure storage conditions comply with moisture sensitivity levels defined in the datasheet to maintain solderability and electrical performance upon installation.

Fixed Inductors Selection Notes

Select this component when a compact shielded inductor is required for automotive or industrial applications. The 1 mH value suits low-frequency filtering needs. The 230 mA rating limits suitability for high-current power stages. Consider the 4.6 Ohm DC resistance for efficiency calculations. Verify footprint compatibility with the 7.3 mm by 7.4 mm dimensions before integration into the PCB layout.

Fixed Inductors Part Context

This part belongs to the WE-PD series of shielded power inductors manufactured by Würth Elektronik. The series is designed for surface mount technology applications requiring robust magnetic shielding. The 7447783102 variant specifically targets automotive markets through AEC-Q200 certification. It complements other values in the series offering different inductance and current capabilities.
