Product Detailed Parameters
- Description：CMC 175UH 10A 2LN TH
- Series：WE-CMB HC
- Mfr：Würth Elektronik
- Package：Tray
- Filter Type：Power Line
- Number of Lines：2
- Current Rating (Max)：10A
- DC Resistance (DCR) (Max)：4mOhm
- Voltage Rating - DC：-
- Voltage Rating - AC：250V
- Operating Temperature：-40°C ~ 125°C
- Ratings：-
- Approval Agency：-
- Features：-
- Mounting Type：Through Hole
- Size / Dimension：0.728" L x 0.571" W (18.50mm x 14.50mm)
- Height (Max)：0.866" (22.00mm)
- Package / Case：Vertical, 4 PC Pin
- Inductance @ Frequency：175 µH @ 100 kHz
- Impedance @ Frequency：-
- Qualification：-
- Grade：-
Download product information
Overview
The Würth Elektronik 74482210002 is a WE-CMB HC series common mode choke designed for power line filtering. It features a through-hole mounting style with an inductance of 175 µH and a maximum DC current rating of 10 A. The component exhibits a maximum DC resistance (DCR) of 4 mOhms, ensuring low insertion loss in high-current applications. It operates within a temperature range of -40°C to +125°C and is constructed for robust performance in demanding electrical environments.
Feature Summary
- High current handling capability suitable for power line applications
- Low DC resistance minimizes power loss and heat generation
- Wide operating temperature range ensures reliability in extreme conditions
Applications
- Power supply input filtering
- Industrial equipment noise suppression
- Automotive electronics protection
Procurement Notes
Verify the specific package type and lead configuration against the official datasheet before integration. Confirm that the 10 A current rating aligns with the thermal management design of the target PCB. Ensure compliance with RoHS directives if required by the end product specifications. Cross-reference the impedance characteristics at the target frequency to validate EMI suppression effectiveness.
Selection Notes
Select this component when high current capacity and low DCR are critical for power line integrity. The WE-CMB HC series offers enhanced performance compared to standard variants. Consider the through-hole form factor for mechanical stability in high-vibration environments. Evaluate the 175 µH inductance value against the specific noise frequencies requiring attenuation in the circuit design.
Part Context
This part belongs to the WE-CMB HC series from Würth Elektronik, specialized for high-current common mode chokes. The series is engineered for robust electromagnetic interference suppression in power circuits. It complements other WE-CMB variants by offering higher current ratings and lower resistance profiles for demanding industrial and automotive applications.
Replacement Considerations
Check for direct substitutes within the WE-CMB HC series with matching 175 µH inductance and 10 A rating. Verify pin compatibility and physical dimensions for existing footprints. Ensure equivalent thermal and electrical performance metrics before substitution.
