7448680180

Overview

The Würth Elektronik 7448680180 is a WE-LPCC series common mode power line choke designed for through-hole mounting. It features an inductance of 150 µH and supports a maximum DC current rating of 20 A. The component exhibits a maximum DC resistance of 1.9 mΩ and is rated for 250 V AC. It operates within a temperature range of -40°C to 115°C.

Feature Summary

• Provides effective common mode noise suppression for power lines
• Engineered for high current handling capabilities up to 20 A
• Utilizes a robust ferrite core structure for stable performance

Applications

• Power supply input filtering
• Industrial equipment EMI suppression
• AC/DC converter stages

Procurement Notes

Verify the specific part number against official manufacturer documentation to confirm electrical ratings and physical dimensions. Ensure compatibility with existing PCB layouts and thermal management requirements before integration into final designs.

Selection Notes

Select this component when high current capacity and low insertion loss are required in power line applications. Consider the through-hole package style and operating temperature range relative to the target environment constraints.

Part Context

This component belongs to the WE-LPCC series, which focuses on common mode chokes for power line interference reduction. The series is characterized by high saturation currents and low DC resistance, suitable for demanding industrial and commercial power electronics environments.

Replacement Considerations

Consult official Wurth Elektronik substitution guides for verified alternatives. Cross-reference inductance, current rating, and physical footprint with equivalent products from other manufacturers if sourcing changes are necessary.
