7488918022

$4.04

Description：WE-MCA SMT-MULTILAYER CHIP ANTEN
Series：WE-MCA
Mfr：Würth Elektronik
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:0b5856b97c94 Category: RF Antennas Brand: Würth Elektronik

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：WE-MCA SMT-MULTILAYER CHIP ANTEN
Series：WE-MCA
Mfr：Würth Elektronik
Package：Tape & Reel (TR),Cut Tape (CT)
RF Family/Standard：802.15.4, Bluetooth, Cellular, Navigation
Frequency Group：Wide Band
Frequency (Center/Band)：830MHz, 2.2GHz
Frequency Range：700MHz ~ 960MHz, 1.71GHz ~ 2.69GHz
Antenna Type：Chip
Number of Bands：2
VSWR：4
Return Loss：-
Gain：2.1dBi, 5.5dBi
Features：-
Termination：-
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Surface Mount
Height (Max)：0.236" (6.00mm)
Applications：Bluetooth, GNSS, GPS, GSM , Wi-Fi, WLAN, Zigbee™
Power - Max：-

Download product information

7488918022

Overview

The Würth Elektronik 7488918022 is a dual-band multilayer chip antenna from the WE-MCA series. It operates across two frequency ranges: 700MHz to 960MHz and 1.71GHz to 2.2GHz, supporting applications such as Bluetooth, GNSS, GPS, GSM, Wi-Fi, WLAN, and Zigbee. The component features a surface-mount package with dimensions of 40mm x 6mm x 5mm. It utilizes solder termination for PCB integration.

Feature Summary

Dual-band operation covering sub-GHz and 2.4GHz ISM bands
Multilayer chip construction for compact integration
Supports multiple wireless protocols including Bluetooth and Zigbee

Applications

Bluetooth connectivity modules
GNSS and GPS positioning devices
Wi-Fi and WLAN communication systems
Zigbee network nodes

Procurement Notes

Verify the specific datasheet version for the 7488918022 model, as external sources may contain conflicting dimensional data or frequency specifications. Confirm RoHS compliance status and moisture sensitivity level (MSL) ratings prior to procurement. Ensure the ordering suffix matches the required tape and reel configuration for automated assembly processes.

Selection Notes

Select this component when dual-band coverage in a single footprint is required for space-constrained designs. Consider the 40mm length relative to available board area. Evaluate impedance matching requirements for both frequency bands during circuit design. Compare against single-band alternatives if only one protocol is utilized to optimize cost and size.

Part Context

This part belongs to the WE-MCA series of multilayer chip antennas manufactured by Würth Elektronik. These components are designed for high-reliability RF applications requiring stable performance across varying environmental conditions. The series offers various sizes and band configurations to suit diverse wireless standards.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Cross-reference with other WE-MCA series variants for similar form factors or frequency ranges if exact substitution is not possible.
