74HCT00N,652

Overview

The 74HCT00N,652 is a quad 2-input NAND gate manufactured by Nexperia. It operates within a supply voltage range of 4.5 V to 5.5 V and supports an ambient temperature range from -40 °C to +125 °C. The device features TTL-level inputs and CMOS low power dissipation. It provides high noise immunity and includes input clamp diodes for interfacing with voltages exceeding VCC. The component complies with JEDEC standards JESD8C and JESD7A.

Feature Summary

• TTL-compatible input levels
• CMOS low power dissipation
• High noise immunity
• Latch-up performance exceeds 100 mA per JESD 78 Class II Level B

Applications

• General digital logic applications
• Signal processing circuits
• Embedded system control logic

Procurement Notes

Verify the specific package type and manufacturer details against official datasheets before procurement. Confirm that the ordering suffix matches the required pin configuration and thermal characteristics. Ensure compliance with RoHS directives and check for any automotive qualification requirements if applicable to the target application environment.

Selection Notes

Select this component when TTL-level compatibility is required alongside CMOS performance. Consider the operating temperature range and supply voltage constraints during design. Evaluate latch-up protection needs and ESD specifications relative to the system's environmental conditions and interface requirements.

Part Context

This part belongs to the 74HCT series of high-speed Si-gate CMOS devices. It is pin compatible with Low-power Schottky TTL (LSTTL). The series offers multiple package options including SO, TSSOP, and QFN variants. The product data sheet revision history indicates ongoing updates to ESD specifications and package outlines.

Replacement Considerations

Check for equivalent parts in the 74HC or 74HCT families from other manufacturers. Verify pinout compatibility and electrical characteristics such as propagation delay and output current capabilities. Ensure the replacement meets the same temperature and voltage specifications.
