Product Detailed Parameters
- Description：IC INVERTER
- Series：*
- Mfr：Nexperia USA Inc.
- Package：Bulk
- Logic Type：-
- Number of Circuits：-
- Number of Inputs：-
- Features：-
- Voltage - Supply：-
- Current - Quiescent (Max)：-
- Current - Output High, Low：-
- Input Logic Level - Low：-
- Input Logic Level - High：-
- Max Propagation Delay @ V, Max CL：-
- Operating Temperature：-
- Mounting Type：-
- Supplier Device Package：-
- Package / Case：-
- Grade：-
- Qualification：-
Download product information
Overview
The 74HCT04PW,112 is a hex inverter integrated circuit manufactured by Nexperia USA Inc. It belongs to the 74HCT logic series and features six independent inverting circuits within a single package. The device operates with a supply voltage range of 4.5V to 5.5V and utilizes a 14-TSSOP surface-mount package. It provides high noise immunity and low power dissipation characteristics typical of CMOS technology while maintaining TTL-compatible input levels.
Feature Summary
- Hex inverter configuration providing six independent signal inversion channels
- TTL-compatible input levels for direct interfacing with TTL logic systems
- High noise immunity and low power dissipation inherent to CMOS construction
Applications
- Signal inversion in digital logic circuits
- Clock signal conditioning and buffering
- General-purpose logic level translation interfaces
Procurement Notes
Verify the specific suffix against official Nexperia documentation to confirm package type and availability status. Distributor listings may vary regarding stock levels and lead times. Ensure the component matches the required 14-TSSOP form factor and HCT logic family specifications for your design. Cross-reference ordering codes with manufacturer datasheets to avoid substitution errors.
Selection Notes
Select this component when a hex inverter with TTL-compatible inputs is required in a compact surface-mount package. The 74HCT series offers a balance between CMOS power efficiency and TTL drive capabilities. Consider the 14-TSSOP footprint for PCB space constraints. Verify operating temperature ranges and ESD protection requirements against application needs before finalizing the selection.
Part Context
This part is a member of the widely used 74HCT logic family, designed for compatibility with standard TTL systems while utilizing CMOS manufacturing processes. The 'PW' designation indicates the TSSOP package variant. As a hex inverter, it serves as a fundamental building block for digital designs requiring signal phase reversal or buffering functions within complex integrated circuits.
