74LCXH16245GX

$1.16

Description：IC TXRX NON-INVERT 3.6V 54FBGA
Series：74LCXH
Mfr：Fairchild Semiconductor
Package：Bulk

SKU:16bbfae9b345 Category: Buffers, Drivers, Receivers, Transceivers Brand: Fairchild Semiconductor

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：IC TXRX NON-INVERT 3.6V 54FBGA
Series：74LCXH
Mfr：Fairchild Semiconductor
Package：Bulk
Logic Type：Transceiver, Non-Inverting
Number of Elements：2
Number of Bits per Element：8
Input Type：-
Output Type：3-State
Current - Output High, Low：24mA, 24mA
Voltage - Supply：2V ~ 3.6V
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：54-LFBGA
Supplier Device Package：54-FBGA (8x5.5)
Grade：-
Qualification：-

Download product information

74LCXH16245GX

Overview

The Fairchild Semiconductor 74LCXH16245GX is a low-voltage, high-speed CMOS device containing sixteen non-inverting bidirectional buffers with three-state outputs. Designed for bus-oriented applications, it operates within a supply voltage range of 2.0V to 3.6V. The component utilizes a 54-pin LFBGA package, facilitating compact integration in portable and battery-powered systems requiring efficient data transmission across multiple lines.

Feature Summary

Contains sixteen non-inverting bidirectional buffers
Features three-state outputs for bus management
Optimized for low-voltage operation
Designed for bus-oriented applications

Applications

Bus-oriented data transmission systems
Portable electronic devices
Battery-powered equipment
High-density digital circuits

Procurement Notes

Verify the specific suffix GX indicates the 54-LFBGA package configuration when sourcing. Confirm RoHS compliance status through official documentation. Ensure the supplier provides genuine Fairchild or onsemi components to avoid counterfeit risks. Check for lead-free certification if required by environmental regulations.

Selection Notes

Select this component for designs requiring sixteen bidirectional channels in a small footprint. It is suitable for systems operating between 2.0V and 3.6V. Consider the 54-LFBGA package for high-density PCB layouts. Verify thermal requirements and pin compatibility during integration.

Part Context

This part belongs to the LCXH series of low-voltage logic devices from Fairchild Semiconductor. It serves as a high-performance transceiver for modern digital interfaces. The series is characterized by fast switching speeds and low power consumption, making it ideal for contemporary consumer electronics and industrial control applications.

Replacement Considerations

Cross-reference documents list SN74AS574DWE4 and DM74AS574WMX as related items, though functional equivalence requires detailed verification. Ensure substitute parts match the 16-bit width and three-state output requirements.
