74LVC02APW,112

Inverter Gates Overview

The 74LVC02APW,112 is a quad 2-input NOR gate from the Nexperia 74LVC02A series. It operates within a wide supply voltage range of 1.2 V to 3.6 V and features overvoltage tolerant inputs up to 5.5 V, enabling direct interfacing with 5 V devices in mixed-voltage applications. The device incorporates Schmitt-trigger action at all inputs for tolerance to slower rise and fall times. It complies with JEDEC standards JESD8-7A, JESD8-5A, and JESD8-C/JESD36. ESD protection exceeds 2000 V (HBM) and 1000 V (CDM. It is specified for operation from -40 °C to +85 °C and -40 °C to +125 °C.

Inverter Gates Feature Summary

• Quad 2-input NOR logic function
• Overvoltage tolerant inputs up to 5.5 V
• Schmitt-trigger action for noise immunity
• CMOS low power consumption

Inverter Gates Applications

• Mixed 3.3 V and 5 V logic translation
• General purpose digital logic processing
• Noise-sensitive signal conditioning

Inverter Gates Procurement Notes

Verify the specific suffix '112' against the official Nexperia datasheet to confirm package type and tape/reel specifications. Confirm current production status via the manufacturer's longevity program, as availability may vary by region. Ensure compliance with RoHS and REACH requirements for your target market before finalizing procurement.

Inverter Gates Selection Notes

Select this component when interfacing 3.3 V logic with 5 V systems due to its 5.5 V input tolerance. Choose the APW package for surface-mount TSSOP applications requiring four independent NOR gates. Consider the Schmitt-trigger inputs if the application involves signals with slow transition times or high noise environments.

Inverter Gates Part Context

This part belongs to the 74LVC02A family, which provides quad 2-input NOR gates. The LVC series is designed for low-voltage CMOS applications, offering compatibility with both 3.3 V and 5 V logic families. The 'APW' designation indicates a TSSOP package, while ',112' specifies the standard tape and reel packaging configuration.

Inverter Gates Replacement Considerations

Check for equivalent parts in the 74LVC02 series from other manufacturers that offer compatible pinouts and electrical characteristics. Verify that any substitute maintains the 5.5 V input tolerance and Schmitt-trigger functionality required for the original design.
