74LVC16374APFG

Overview

The Renesas Electronics Corporation 74LVC16374APFG is a 16-bit edge-triggered D-type flip-flop featuring positive logic and three-state outputs. Constructed using advanced dual metal CMOS technology, this component operates within a voltage range of 2.0V to 3.6V. It provides high-speed performance with low power consumption, making it suitable for battery-powered applications. The device includes an asynchronous clear function and is housed in a 48-pin TSSOP package.

Feature Summary

• Advanced dual metal CMOS construction ensures high speed and low power operation
• Asynchronous clear function allows immediate reset of all flip-flops
• Three-state outputs facilitate direct bus line connections without additional drivers

Applications

• Portable consumer electronics requiring low voltage operation
• Battery-powered systems prioritizing energy efficiency
• High-speed data acquisition and processing circuits

Procurement Notes

Verify the specific suffix 'APFG' against official Renesas documentation to confirm the exact package type (TSSOP-48) and temperature range. Ensure compatibility with system voltage levels between 2.0V and 3.6V. Check for any recent product discontinuance notifications or alternative part recommendations from the manufacturer before finalizing procurement plans.

Selection Notes

Select this component when designing systems that require 16-bit parallel data storage with low power consumption. It is appropriate for applications operating at 3.3V or 2.5V logic levels. Consider the TSSOP-48 package constraints regarding board space and thermal management. Verify that the asynchronous clear feature meets the system's reset requirements.

Part Context

This part belongs to the LVC (Low Voltage CMOS) family of logic ICs from Renesas Electronics. It is designed as a successor to older 5V logic families, offering improved performance and lower power dissipation. The 16374 series specifically addresses the need for high-density memory elements in compact electronic devices.

Replacement Considerations

Consult official Renesas substitution guides for equivalent parts if this specific variant is unavailable. Direct replacements must match the 16-bit configuration, 2.0V-3.6V operating range, and TSSOP-48 package.
