74LVC1G02GX,125

Inverter Gates Overview

The Nexperia 74LVC1G02GX,125 is a single 2-input NOR gate from the LVC logic family. It operates within a supply voltage range of 1.65 V to 5.5 V and supports output drive currents up to ±32 mA. The device features Schmitt-trigger inputs for noise tolerance and includes I_OFF circuitry for partial power-down protection. It is specified for operation across an extended temperature range of -40 °C to +125 °C.

Inverter Gates Feature Summary

• Schmitt-trigger action at all inputs provides tolerance for slower input rise and fall times.
• I_OFF circuitry disables outputs during partial power-down to prevent damaging backflow current.
• Inputs are overvoltage tolerant to 5.5 V, enabling direct interface with TTL levels.

Inverter Gates Applications

• Mixed 3.3 V and 5 V environments
• Partial power-down applications
• Signal buffering and line driving

Inverter Gates Procurement Notes

Verify the specific suffix 'GX' against official Nexperia documentation to confirm the exact package type and tape-and-reel specifications. Ensure that the selected variant meets the required operating temperature range and ESD protection standards for your specific application environment before finalizing procurement.

Inverter Gates Selection Notes

Select this component when a single 2-input NOR function is required in space-constrained designs. It is suitable for mixed-voltage systems due to its wide supply range and overvoltage-tolerant inputs. Consider the I_OFF feature if the design requires safe operation during partial power-down states.

Inverter Gates Part Context

This part belongs to the Nexperia 74LVC (Low Voltage CMOS) logic family, designed for low-power applications. The 74LVC1G series offers single-gate solutions in compact packages, facilitating efficient board layout while maintaining high-speed performance and compatibility with standard digital logic interfaces.

Inverter Gates Replacement Considerations

Check for equivalent parts such as the 74LVC1G02GW or other variants within the same family that may offer different packaging options like TSSOP or X2SON while maintaining identical logical functionality and electrical characteristics.
