74LVC1G175GN,132

Overview

The Nexperia 74LVC1G175GN,132 is a single D-type flip-flop in the 74LVC logic series. It features a positive-edge triggered clock input and non-inverting output within a 6-TSSOP package. The device operates on a supply voltage range of 1.65 V to 5.5 V, supporting mixed 3.3 V and 5 V environments. It provides an output drive current of ±32 mA and exhibits low static power consumption. The component is specified for operation across temperatures from -40 °C to +125 °C.

Feature Summary

• Positive-edge triggered D-type flip-flop with non-inverting output
• Overvoltage tolerant inputs compatible with 3.3 V and 5 V systems
• High noise immunity and low power dissipation characteristics
• I_OFF circuitry enables partial power-down mode protection

Applications

• Data storage and register applications
• Timing control circuits
• Mixed-signal interface buffering
• General-purpose digital logic systems

Procurement Notes

Verify the specific suffix GN,132 against official Nexperia documentation to confirm the TSSOP-6 package configuration and reel quantity specifications. Ensure that the requested part number matches the exact manufacturing revision required for your design. Cross-reference the datasheet for any recent product change notifications or assembly updates before finalizing procurement orders.

Selection Notes

Select this component when a single-bit storage element with high-speed performance is required in low-voltage designs. The wide supply voltage range allows flexibility in system architecture. Consider the TSSOP package constraints for PCB layout. Verify that the 32 mA output drive capability meets the load requirements of the downstream circuitry without exceeding thermal limits.

Part Context

This component belongs to the 74LVC family of low-voltage CMOS logic devices. The 74LVC1G175 specifically denotes a single D-type flip-flop. The GN,132 suffix indicates the TSSOP-6 surface-mount package and standard tape-and-reel packaging format. This series is designed for applications requiring high speed and low power consumption in portable and battery-operated devices.

Replacement Considerations

Check Nexperia's official substitution list for equivalent parts such as the 74LVC1G175GM variants if package changes are acceptable. Verify pinout compatibility and electrical parameters before substituting.
