74LVC1G74GD/C4H

Overview

The 74LVC1G74GD/C4H is a single D-type flip-flop logic integrated circuit manufactured by Nexperia USA Inc. This device features one positive-edge triggered D-type flip-flop element with separate data (D) and clock (CLK) inputs, along with set (SET) and reset (RESET) functions. It operates within a supply voltage range of 1.65V to 3.6V and is housed in an 8-XFDFN package.

Feature Summary

• Single D-type flip-flop configuration for digital signal timing and data capture
• Positive-edge triggering mechanism for sequential logic applications
• Integrated set and reset control functions for state management

Applications

• Digital signal timing circuits
• Data capture systems
• Sequential logic design

Procurement Notes

Verify component authenticity through official Nexperia channels or authorized distributors. Confirm the specific suffix GD/C4H matches project requirements. Check current manufacturing status as availability may vary. Ensure compliance with RoHS standards if required by the application environment.

Selection Notes

Select this component for low-voltage applications requiring a single D-type flip-flop. The 1.65V to 3.6V operating range suits battery-powered devices. The XFDFN package offers compact surface-mount integration. Consider pin compatibility and electrical characteristics against existing system designs before implementation.

Part Context

This part belongs to the 74LVC series of high-speed CMOS logic devices. The series is known for low power consumption and wide voltage operation. The 74LVC1G74 variant specifically provides a single flip-flop in a small footprint, suitable for space-constrained electronic designs.

Replacement Considerations

Check for direct equivalents such as the 74LVC1G74GT,115 from NXP/Nexperia. Verify package dimensions and pinout compatibility when substituting. Ensure voltage levels and switching speeds meet original specifications.
