74LVC1G80GN,132

Overview

The 74LVC1G80GN,132 is a single D-type flip-flop from the Nexperia LVC logic family. It operates within a supply voltage range of 1.65 V to 5.5 V and features positive-edge triggering. The component provides one bit of storage with an inverted output in a compact XSON-6 package. It supports mixed 3.3 V and 5 V environments and includes I_OFF circuitry for partial power-down applications.

Feature Summary

• Positive-edge triggered D-type flip-flop functionality
• I_OFF circuitry prevents damaging backflow current during partial power-down
• Inputs tolerant to 5.5 V for mixed voltage system integration

Applications

• Data storage and synchronization in digital circuits
• Signal processing systems requiring edge-triggered state retention
• Mixed voltage interface designs between 3.3 V and 5 V domains

Procurement Notes

Verify the specific suffix '132' against official Nexperia documentation to confirm the exact XSON-6 packaging configuration and reel specifications. Ensure that the selected variant aligns with the required thermal performance and moisture sensitivity level for the intended application environment before finalizing procurement orders.

Selection Notes

Select this component when a single-bit memory element with an inverted output is required in space-constrained designs. The wide supply voltage range and overvoltage-tolerant inputs make it suitable for interfacing with various logic families. Consider the XSON-6 package dimensions and thermal characteristics relative to PCB layout constraints.

Part Context

This device belongs to the 74LVC1G80 series of single D-type flip-flops. It shares functional characteristics with other members of the LVC family but differs in physical packaging. The GN suffix specifically denotes the XSON-6 package type, distinguishing it from TSSOP or VSON variants within the same logical product line.

Replacement Considerations

Direct substitutes include 74LVC1G80GF (VSON-6) and 74LVC1G80GW (TSSOP-5). Verify pin compatibility and thermal requirements when substituting packages.
