74LVC1GU04GM,132

Inverter Gates Overview

The 74LVC1GU04GM,132 is a single unbuffered inverter from the Nexperia 74LVC logic family. It operates within a supply voltage range of 1.65 V to 5.5 V and supports CMOS/LVTTL logic switching levels. The device provides an output drive capability of ±32 mA at VCC = 3.0 V. It is specified for ambient temperatures ranging from -40 °C to +125 °C. The component utilizes a 6-XSON (SOT886) surface-mount package.

Inverter Gates Feature Summary

• Provides signal inversion functionality with overvoltage tolerant inputs up to 5.5 V
• Enables direct interface with TTL levels while maintaining high noise immunity
• Supports mixed 3.3 V and 5 V environments through wide supply voltage compatibility

Inverter Gates Applications

• Signal level translation between different voltage domains
• General-purpose digital logic inversion in low-power systems
• Interface circuits requiring high noise immunity

Inverter Gates Procurement Notes

Verify the specific suffix '132' corresponds to the required tape-and-reel packaging configuration. Confirm that the 6-XSON SOT886 footprint matches the target PCB layout dimensions. Ensure the selected variant meets the required operating temperature range of -40 °C to +125 °C for the intended application environment.

Inverter Gates Selection Notes

Select this component when a single-channel inverter is required with robust overvoltage tolerance. The wide supply voltage range allows flexibility in power design. Consider the ±32 mA drive capability for moderate load requirements. Verify that the small form factor fits within space-constrained board designs.

Inverter Gates Part Context

This part belongs to the 74LVC series, designed for low-voltage CMOS applications. It shares functional similarities with other single-gate inverters but offers specific drive strength and voltage tolerance characteristics defined by the LVC standard. The MicroPak™ packaging option provides a compact solution for modern electronics.

Inverter Gates Replacement Considerations

Cross-reference with other single inverters in the 74LVC family such as the 74LVC1G04 variants. Verify pinout compatibility and electrical specifications before substitution. Ensure the alternative device supports the same supply voltage range and output current requirements.
