74LVC32245AEC,518

Overview

The Nexperia 74LVC32245AEC,518 is a 32-bit bus transceiver featuring four non-inverting elements with eight bits per element. It utilizes a 96-LFBGA package measuring 13.5x5.5 mm. The device supports a wide supply voltage range from 2.3 V to 3.6 V and incorporates CMOS low power consumption characteristics. Inputs and outputs are designed to be 5 V tolerant, facilitating direct interfacing with 5 V logic systems without requiring level shifting components.

Feature Summary

• Provides 32-channel bidirectional data transmission via four independent 8-bit elements
• Features 5 V tolerant inputs and outputs for seamless integration with 5 V logic families
• Operates within a wide supply voltage range of 2.3 V to 3.6 V
• Utilizes CMOS technology to ensure low power consumption during operation

Applications

• High-density memory bus interfaces in embedded systems
• Interfacing between low-voltage processors and 5 V peripheral devices
• Data routing in portable electronic equipment requiring power efficiency
• Industrial control systems utilizing mixed voltage logic levels

Procurement Notes

Verify the specific suffix '518' corresponds to the 96-LFBGA (13.5x5.5) package configuration when sourcing. Confirm that the component meets the required 5 V tolerance specifications for your target interface. Ensure compatibility with the 2.3 V to 3.6 V supply voltage range defined in the official datasheet before finalizing procurement orders.

Selection Notes

Select this component when a high-channel-count transceiver is required for mixed-voltage environments. The 96-LFBGA package offers a compact footprint suitable for space-constrained designs. Consider the 5 V tolerance feature if interfacing directly with legacy 5 V logic without additional level shifters. Verify that the operating voltage range aligns with the system's power supply architecture.

Part Context

This part belongs to the Nexperia LVC/LCX/Z series of bus transceivers. It is functionally similar to other 32-bit transceivers but distinguished by its specific package type and voltage tolerance profile. The 'AEC' designation indicates automotive-grade qualification, while '518' specifies the tape and reel packaging format for automated assembly processes.

Replacement Considerations

Direct substitutes include the 74LVC32245AEC,557 and 74LVC32245AEC,518 variants which share identical electrical characteristics. Ensure any replacement maintains the 96-LFBGA pinout and physical dimensions. Verify that alternative parts also support the 2.3 V to 3.6 V supply range and 5 V tolerance requirements.
