74LVC3G07GN,115

Overview

The Nexperia 74LVC3G07GN,115 is a triple buffer and line driver within the LVC logic family. It features three non-inverting inputs and open-drain outputs in an X2SON8 package. The device operates from 1.65 V to 5.5 V with low static current of 100 nA and high drive capability of 32 mA. It supports surface mount installation and functions across a temperature range of -40°C to +125°C.

Feature Summary

• Provides three independent non-inverting buffering channels for signal integrity.
• Features open-drain output configuration suitable for voltage level translation.
• Operates across a wide supply voltage range from 1.65 V to 5.5 V.

Applications

• Voltage level shifting between different logic families
• Driving open-drain buses such as I2C or SMBus
• General purpose buffering in portable electronic devices

Procurement Notes

Verify the specific suffix GN corresponds to the X2SON-8 package when sourcing. Confirm RoHS compliance and REACH status via official Nexperia documentation prior to integration. Ensure the ordering part number matches the required tape and reel specifications for automated assembly processes.

Selection Notes

Select this component for designs requiring open-drain outputs with high current drive capabilities. It is suitable for mixed-signal environments where voltage translation between 1.65 V and 5.5 V domains is necessary. Consider the small footprint of the X2SON-8 package for space-constrained PCB layouts.

Part Context

This part belongs to the 74LVC series of low-voltage CMOS logic ICs. It shares functional similarities with other triple buffers but is distinct due to its open-drain output type. The GN suffix indicates the specific X2SON-8 packaging variant offered by Nexperia for surface-mount applications.

Replacement Considerations

Check for direct substitutes like the 74LVC3G07GS,115 which uses an XSON-8 package. Verify pin compatibility and electrical parameters before swapping packages.
