74LVT16244BDL,118

Overview

The Nexperia 74LVT16244BDL,118 is a 16-bit buffer and line driver belonging to the LVT logic family. It features non-inverting outputs with three-state capability, allowing for effective bus management in digital systems. The device operates within a supply voltage range of 2.7 V to 3.6 V and is housed in a 48-pin SSOP package. Designed for high-speed applications, it provides robust signal integrity for driving multiple loads across parallel data buses.

Feature Summary

• Provides 16-bit buffering and line driving capabilities for high-speed digital interfaces
• Features three-state outputs to facilitate efficient bus sharing and system isolation
• Supports mixed voltage environments through overvoltage tolerant inputs

Applications

• Parallel data bus drivers in computing systems
• Memory address and data register buffering
• Clock distribution networks requiring high fan-out

Procurement Notes

Verify the specific suffix '118' against official Nexperia documentation to confirm tape-and-reel packaging specifications. Ensure compatibility with existing PCB footprints for the 48-pin SSOP variant. Cross-reference lead times and lifecycle status directly with authorized distributors, as availability may vary by region.

Selection Notes

Select this component when a 16-bit wide buffer with three-state control is required for 3.3 V logic systems. Consider the LVT family for its balance of speed and power consumption compared to standard TTL or CMOS alternatives. Verify that the input voltage levels match the source device output characteristics to ensure reliable switching thresholds.

Part Context

This part belongs to the Nexperia 74LVT series, which is optimized for low-voltage operation while maintaining compatibility with higher voltage I/O standards. The 74LVT16244 variant specifically addresses the need for wide-bus buffering in portable and battery-powered electronics where power efficiency is critical.

Replacement Considerations

Check for direct pin-compatible substitutes within the same LVT family, such as the 74LVT16244ADL. Verify that alternative packages meet the thermal and mechanical requirements of the design.
