750315740

$2.69

Description：CMC 6MH 450MA 2LN SMD
Series：MID-D11
Mfr：Würth Elektronik
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:7922d41be803 Category: Common Mode Chokes Brand: Würth Elektronik

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：CMC 6MH 450MA 2LN SMD
Series：MID-D11
Mfr：Würth Elektronik
Package：Tape & Reel (TR),Cut Tape (CT)
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：450mA
DC Resistance (DCR) (Max)：1.6Ohm (Typ)
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-40°C ~ 125°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Surface Mount
Size / Dimension：-
Height (Max)：0.372" (9.45mm)
Package / Case：Horizontal, 4 Gull Wing
Inductance @ Frequency：6 mH @ 10 kHz
Impedance @ Frequency：-
Qualification：-
Grade：-

Download product information

750315740

Overview

The Würth Elektronik part number 750315740 is a surface-mount common mode choke from the MID-D11 series. It features an EE11/6/3 core design with an inductance of 6 mH at 10 kHz and a maximum DC resistance of 1.6 Ohms. The component supports a current rating of 450 mA and operates within a temperature range of -40°C to +125°C.

Feature Summary

Dual-line configuration for effective suppression of asymmetric interferences
Compact SMD footprint suitable for space-constrained designs
High common mode rejection capability

Applications

Power line filtering
Signal integrity protection
EMI suppression in compact electronics

Procurement Notes

Verify the specific datasheet version and RoHS compliance status directly with Wurth Elektronik or authorized distributors before integration. Confirm that the 450mA current rating and 1.6 Ohm DCR meet your circuit requirements. Ensure the SMD package dimensions align with your PCB layout constraints.

Selection Notes

Select this component when high-frequency noise suppression is required on dual lines within a limited board area. The 6 mH inductance provides significant impedance at 10 kHz, making it suitable for general power line applications. Consider the 450mA limit for continuous operation.

Part Context

This component belongs to the MID-D11 family of dual-coil common mode chokes. These parts utilize an EE11/6/3 core structure to deliver balanced performance for both lines. The series is designed for surface-mount assembly, offering reliability in automated manufacturing processes.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Verify compatibility with existing footprints if considering alternative manufacturers.
