75168-301-05

Headers, Male Pins Overview

The Amphenol ICC (FCI) 75168-301-05 is a BergStik series connector header designed for board-to-board applications. It features a single row of five male pin contacts with a 2.54mm pitch. The component utilizes a right-angle through-hole mounting style and push-pull retention mechanism. Contact materials consist of phosphor bronze with gold plating, ensuring reliable electrical performance.

Headers, Male Pins Feature Summary

• Right-angle unshrouded header configuration
• Push-pull mechanical retention system
• Gold-plated phosphor bronze contacts

Headers, Male Pins Applications

• Board-to-board interconnects
• High-density electronic assemblies
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify the specific contact length and insulation height against current datasheets before integration. Confirm RoHS compliance status as manufacturing locations may vary. Ensure the right-angle orientation matches the PCB layout requirements to avoid mechanical interference with adjacent components or enclosures.

Headers, Male Pins Selection Notes

Select this part when a low-profile right-angle connection is required in constrained spaces. The 2.54mm pitch ensures compatibility with standard mating connectors. Consider the push-pull feature if frequent insertion and removal cycles are anticipated during assembly or maintenance procedures.

Headers, Male Pins Part Context

This component belongs to the BergStik family of 2.54mm headers known for robust mechanical stability. The 75168 prefix specifically denotes the right-angle variant within the product line. It serves as a critical interface element in various commercial and industrial electronic devices requiring secure signal transmission.

Headers, Male Pins Replacement Considerations

• 75168-301-05LF
