Headers, Male Pins Overview

The Molex 75757-5261 is a dual-row vertical header within the MX150 sealed connector system, designed for automotive and commercial vehicle applications. It features 12 circuits with a straight mounting angle and supports currents up to 22A. The component operates between -40°C and +125°C. Contact plating consists of 1.25µm minimum nickel overall with 2.50µm minimum select matte tin on tails.

Headers, Male Pins Feature Summary

• Dual-row configuration supporting both signal and power transmission
• Sealed design compatible with SAE- and ISO-style wire harnesses
• Vertical PCB mounting orientation for space-efficient assembly

Headers, Male Pins Applications

• Automotive electronic control units
• Commercial vehicle wiring systems
• SAE-standardized interconnects

Headers, Male Pins Procurement Notes

Verify the part number suffix against official Molex documentation to confirm specific plating thickness and housing material variations. Ensure compatibility with designated USCAR interface requirements for the target application environment.

Headers, Male Pins Selection Notes

Select this component when a dual-row vertical header is required for high-current automotive signals. Confirm that the 12-circuit count matches the design needs and that the operating temperature range meets environmental specifications.

Headers, Male Pins Part Context

This part belongs to the MX150 series, which provides sealed connectivity solutions for demanding environments. The system is engineered to withstand vibration and moisture, making it suitable for under-hood and exterior vehicle installations where reliability is critical.

Headers, Male Pins Replacement Considerations

Consult Molex official cross-reference lists for verified substitutes. Generic rectangular headers may not match the sealed interface or current rating requirements.
