76600/1C

Overview

The Murata Power Solutions 76600/1C is a through-hole pulse transformer designed for signal isolation and coupling. It features a 1:1 turns ratio with an inductance of 111.7mH and a saturation voltage-time product of 50.5Vus. The component measures 12.7 mm in length, 8.89 mm in width, and 5.84 mm in height. It operates within a temperature range of 0°C to +70°C.

Feature Summary

• Provides galvanic isolation via magnetic coupling
• Through-hole mounting for PCB integration
• High inductance for effective signal transmission

Applications

• Microcontroller interface circuits
• Digital signal isolation
• Pulse waveform transmission

Procurement Notes

This component is officially classified as obsolete by the manufacturer. Availability is restricted to remaining stock from authorized distributors or secondary markets. Verify part authenticity and condition carefully when sourcing from non-primary channels due to end-of-life status.

Selection Notes

Select this component only if legacy compatibility is required. Ensure the circuit design accommodates the specific inductance and saturation limits. Consider alternative modern pulse transformers if new designs allow for updated specifications and availability.

Part Context

Part of the 766 series from Murata Power Solutions, focusing on pulse transformers. This series supports various isolation needs in electronic systems. The 76600/1C represents a specific configuration within this family, now discontinued.

Replacement Considerations

No public confirmed substitute part numbers are available.
