77315-102-02LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 77315-102-02LF is a BergStik header connector featuring 2 positions with a 2.54 mm pitch. It utilizes a single-row, right-angle solder pin termination for board-to-board applications. The contacts are gold-plated phosphor bronze rated for 3 A at 1.5 kV. The black thermoplastic housing operates between -65°C and +130°C, providing 5 GOhms insulation resistance.

Headers, Male Pins Feature Summary

• Right-angle unshrouded design for compact board-to-board interconnects
• Gold-plated phosphor bronze contacts ensure reliable signal transmission
• Thermoplastic housing meets UL 94 V-0 flammability standards

Headers, Male Pins Applications

• Board-to-board connections in industrial equipment
• Interconnects for instrumentation and measurement devices
• Connections within factory automation systems

Headers, Male Pins Procurement Notes

Verify the specific suffix against official Amphenol documentation to confirm exact contact length and plating thickness specifications. Ensure the RoHS compliance status matches current regulatory requirements for your target market. Confirm that the bulk packaging quantity aligns with your assembly line handling capabilities before finalizing the order.

Headers, Male Pins Selection Notes

Select this component when a low-profile, right-angle male header is required for dense circuit layouts. The 2.54 mm pitch accommodates standard PCB drilling patterns. Verify that the mating socket or cable assembly matches the 5.72 mm contact length to ensure proper engagement depth and mechanical stability during operation.

Headers, Male Pins Part Context

This part belongs to the BergStik family of connectors, designed for high-reliability interconnect solutions. The series offers various position counts and row configurations to support diverse electronic assembly needs. As an FCI product, it adheres to strict manufacturing quality standards for consistent performance across different industrial environments.

Headers, Male Pins Replacement Considerations

Consult official cross-reference guides for compatible substitutes. Ensure replacement parts maintain identical 2.54 mm pitch, right-angle orientation, and 3 A current rating to preserve system integrity and physical fitment.
