77315-824-16LF

Headers, Male Pins Overview

The Amphenol ICC (FCI) 77315-824-16LF is a BergStik® unshrouded header connector designed for board-to-board applications. It features a 16-position, single-row configuration with a 0.100-inch (2.54mm) pitch. The component utilizes male pin contacts made of phosphor bronze, finished with gold plating over nickel to ensure reliable signal transmission. Designed for right-angle through-hole mounting, the connector employs a push-pull locking mechanism for secure attachment. The housing is constructed from black thermoplastic material rated UL94 V-0 for flammability, supporting an operating temperature range of -65°C to +130°C.

Headers, Male Pins Feature Summary

• Right-angle through-hole mounting style facilitates compact board-to-board interconnections.
• Gold-plated phosphor bronze contacts provide durable and low-resistance electrical pathways.
• Push-pull locking system ensures secure mechanical retention during operation.
• Unshrouded design allows for flexible integration in space-constrained layouts.

Headers, Male Pins Applications

• Board-to-board interconnects
• High-density electronic assemblies
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's current documentation to confirm contact finish and plating thickness specifications. Confirm that the lead time aligns with project schedules, as availability may vary. Ensure the procurement channel is authorized to guarantee component authenticity and traceability. Check for any recent product change notices or lifecycle status updates prior to finalizing orders.

Headers, Male Pins Selection Notes

Select this component when a right-angle, unshrouded header with a 2.54mm pitch is required. The gold contact finish is suitable for environments demanding high reliability and corrosion resistance. Verify that the PCB layout accommodates the right-angle orientation and the necessary clearance for the push-pull locking mechanism. Ensure the thermal rating meets the operational requirements of the target application.

Headers, Male Pins Part Context

This part belongs to the BergStik® family of connectors, which are widely used in various electronic industries. The series offers diverse configurations including shrouded and unshrouded options with different row counts and contact finishes. The 77315 base number indicates a specific header variant within the broader FCI portfolio, emphasizing robust performance in standard interconnect scenarios.

Headers, Male Pins Replacement Considerations

Consult official substitution guides for compatible alternatives. Verify that any substitute matches the 2.54mm pitch, 16-position count, and right-angle mounting style. Ensure the replacement maintains the same contact material and plating specifications to preserve electrical performance and mechanical fit.
