Headers, Receptacles, Female Sockets Overview

Molex part number 79107-7003 is a Milli-Grid series board-to-board receptacle connector. It features an 8-position configuration arranged in a dual-row layout with a 2.00 mm centerline pitch. The component utilizes through-hole termination for vertical surface mounting on printed circuit boards. Contact surfaces are finished with selective gold plating to ensure reliable electrical performance. The design supports standard PCB assembly processes and provides secure mechanical retention within the target system.

Headers, Receptacles, Female Sockets Feature Summary

• Dual-row receptacle architecture supporting high-density interconnect applications
• Vertical through-hole mounting orientation for stable PCB integration
• Selective gold contact plating for enhanced conductivity and corrosion resistance

Headers, Receptacles, Female Sockets Applications

• High-density board-to-board signal transmission systems
• Industrial control module interconnections
• Telecommunications equipment internal connectivity

Headers, Receptacles, Female Sockets Procurement Notes

Verify that the specific ordering suffix matches the required contact plating and tail length specifications. Confirm that the selected variant aligns with the intended through-hole assembly process and thermal profile requirements. Ensure compatibility with mating header components from the same Milli-Grid family to maintain proper alignment and electrical continuity during operation.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a low-profile, dual-row receptacle is required for vertical board stacking or adjacent board connections. Consider the 2.00 mm pitch constraint and the need for through-hole soldering capabilities. Evaluate the mechanical stability provided by the vertical orientation against available panel space and mating connector height restrictions.

Headers, Receptacles, Female Sockets Part Context

This receptacle belongs to the Molex Milli-Grid product line, which is engineered for compact electronic assemblies requiring reliable signal integrity. The series offers various pin counts and configurations to support diverse board-to-board interface needs while maintaining consistent dimensional tolerances across the family.

Headers, Receptacles, Female Sockets Replacement Considerations

Compatible substitutes include other 2.00 mm pitch dual-row through-hole receptacles with identical pin counts. Verify that alternative parts match the vertical mounting style and contact plating specifications to ensure functional equivalence in the final assembly.
