800-10-002-20-001000

Headers, Male Pins Overview

The Mill-Max Manufacturing Corp. model 800-10-002-20-001000 is a vertical pin header connector designed for through-hole mounting on printed circuit boards. This component features two positions with a standard 0.100-inch (2.54 mm) contact spacing, accommodating single-row configurations. The contacts are constructed from beryllium copper and finished with gold plating to ensure reliable electrical conductivity and corrosion resistance. It utilizes a push-pull fastening mechanism for secure mating. The unit operates within a temperature range of -55°C to 125°C and supports a rated current of 3 A at 150 VDC.

Headers, Male Pins Feature Summary

• Vertical orientation with through-hole termination for stable PCB integration
• Gold-plated beryllium copper contacts ensuring high reliability
• Push-pull fastening mechanism for secure connection retention

Headers, Male Pins Applications

• Board-to-board interconnections
• General electronic assembly
• Industrial control systems

Headers, Male Pins Procurement Notes

Verify the specific manufacturer designation when sourcing this part, as distribution channels may list it under Preci-Dip due to manufacturing agreements. Confirm that the ordering suffix matches the required contact finish and insulation material specifications. Ensure compatibility with mating sockets regarding row count and pitch dimensions before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this connector for applications requiring low-profile vertical headers with robust mechanical retention. The 2-position configuration is suitable for compact designs needing minimal board space. Verify that the 3 A current rating aligns with the system's power requirements and that the operating temperature range meets environmental conditions.

Headers, Male Pins Part Context

This component belongs to the 800 series of precision-machined interconnects manufactured by Mill-Max. The series is recognized for high-reliability performance in demanding environments. As a leader in custom and standard interconnects, Mill-Max ensures consistent quality through integrated US-based manufacturing processes.

Headers, Male Pins Replacement Considerations

Compatible substitutes include models from the same 800 series family, such as 800-10-002-61-001000 or 800-90-002-61-001000, provided they match the 2-position count, 2.54 mm pitch, and vertical orientation. Always verify that the replacement maintains identical contact materials and plating thicknesses.
