800-10-002-40-002000

Headers, Male Pins Overview

The Mill-Max 800-10-002-40-002000 is a surface mount header connector featuring two positions with a 0.100-inch (2.54mm) pitch. It utilizes a straight board-to-board style configuration designed for direct PCB integration. The component employs male pin contacts to establish reliable electrical pathways within compact electronic assemblies.

Headers, Male Pins Feature Summary

• Surface mount technology enables automated placement and secure attachment to printed circuit boards.
• Male pin contact configuration ensures compatibility with standard mating receptacles.

Headers, Male Pins Applications

• Board-to-board interconnection in compact electronics
• Surface mount assembly for low-pin-count signal routing
• Industrial control module interface connections

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against official Mill-Max documentation to confirm exact termination and plating specifications. Ensure the selected variant matches the required surface mount footprint and pitch dimensions for the target application design.

Headers, Male Pins Selection Notes

Select this component when a minimal two-position surface mount header is required. Confirm that the 0.100-inch pitch aligns with the system's spacing requirements and that the male pin style matches the intended mating connector type.

Headers, Male Pins Part Context

This part belongs to the Mill-Max 800 series, which specializes in precision-machined headers and wire housings. The series provides standardized interconnect solutions for various mounting styles and pin counts, supporting diverse electronic manufacturing needs.

Headers, Male Pins Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing designs before considering alternative sources.
