800-10-004-40-002000

$5.72

Description：CONN HEADER SMD 4POS 2.54MM
Series：800
Mfr：Mill-Max Manufacturing Corp.
Package：Bulk

SKU:56d1a7933b8b Category: Headers, Male Pins Brand: Mill-Max Manufacturing Corp.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

800-10-004-40-002000 is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Mill-Max Manufacturing Corp.. Its product description is CONN HEADER SMD 4POS 2.54MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for 800-10-004-40-002000

Description：CONN HEADER SMD 4POS 2.54MM
Series：800
Mfr：Mill-Max Manufacturing Corp.
Package：Bulk
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：4
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board
Shrouding：Unshrouded
Mounting Type：Surface Mount
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.147" (3.73mm)
Contact Length - Post：-
Overall Contact Length：-
Insulation Height：0.110" (2.79mm)
Contact Shape：Circular
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：10.0µin (0.25µm)
Contact Finish - Post：-
Contact Material：Brass
Insulation Material：Polyamide (PA46), Nylon 4/6
Features：-
Operating Temperature：-55°C ~ 125°C
Ingress Protection：-
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：-
Voltage Rating：-

Headers, Male Pins datasheet and documents for 800-10-004-40-002000

800-10-004-40-002000

Headers, Male Pins Overview

The Mill-Max 800-10-004-40-002000 is a surface mount board connector header featuring four positions with a 0.100-inch (2.54mm) pitch. It utilizes a straight mounting style and includes matte tin over nickel contact finishes for reliable electrical performance. The component is designed for direct PCB integration without shrouding, supporting standard interconnect requirements.

Headers, Male Pins Feature Summary

Surface mount construction for automated assembly
Unshrouded header design for compact layouts
Matte tin over nickel contact plating

Headers, Male Pins Applications

LED testing fixtures
Diode testing applications
General board-to-board interconnects

Headers, Male Pins Procurement Notes

Verify the specific RoHS compliance status and lead times directly with Mill-Max or authorized distributors, as availability may vary. Confirm that the surface mount footprint matches your PCB design constraints before finalizing procurement orders to ensure proper installation.

Headers, Male Pins Selection Notes

Select this part for low-profile surface mount applications requiring a four-position unshrouded header. Ensure the mating connector aligns with the 0.100-inch pitch specification. Consider the lack of shrouding when designing enclosure clearances to prevent short circuits during mating.

Headers, Male Pins Part Context

This component belongs to the Mill-Max 800 series of precision-machined interconnects. The series is known for high-reliability connectors used in demanding industrial and defense environments. The 800 series offers various pin counts and mounting options for diverse electronic integration needs.
